Logitech Video Conferencing - BCC950 ConferenceCam

Logitech fills the gap between a simple webcam and a group videoconferencing system: a new portable USB videoconferencing camera, the BCC950 ConferenceCam - 960-000866. It has a pan-tilt-zoon (PTZ) HD 1080p camera and speakerphone in one unit and a remote control. It attaches to a PC or Mac via USB.

Shipping since June, 2012.  MSRP: $249.99

Here are some design examples of a videoconferencing room

A pre-ConferenceCam Huddle around a webcam & laptop	Pre ConferenceCam video received	ConferenceCam in use on an oval table	ConferenceCam in use with a rectangular table	ConferenceCam with VFI VC-Table & VSS-1

  The camera is capable of 1080p video capture at 30 frames per second. It has an integrated, omni-directional microphone that can capture audio from 360 degrees around the base unit, plus a small built-in speaker, a remote control, etc.

Motorized pan, tilt and zoom Integrated full duplex omni-directional speakerphone with 8-foot range On-board H.264 encoding USB video class (UVC) supported applications Full HD 1080p30fps video calling Camera and speakerphone controls, speakerphone and remote control 10-foot range remote control Pan, tilt and zoom, Volume, Audio mute, Answer/Hang up Carl Zeiss Optics with 9 point auto focus 78-degree field of view 180-degree pan, 55-degree tilt 3.5mm analog headset jack USB 2.0 compliant 8-foot USB cable

8-foot universal power adapter 9-inch extender stem for elevation / eye level camera angle Compatibility: USB video class (camera and H.264), Microsoft Lync, Skype Windows 7, XP, and Mac OS X 10.6 and higher System Requirements - UVC mode (No software installation required) Windows® XP, Windows Vista®, or Windows® 7, Mac OS X 10.6 and above Application Compatibility: Microsoft® Lync™, Microsoft® Office 365/Lync Online, Skype™ Warranty Information 2-year limited hardware warranty Part Number PN 960-000866 https://www.logitech.com/assets/43139/bcc950-quickstart-guide.pdf - quick start guide https://www.logitech.com/assets/43140/bcc950-addendum.pdf - addendum https://www.logitech.com/en-us/for-business/products/webcams/devices/conferencecam - main page https://www.logitech.com/en-us/support-downloads/downloads/business-products/devices/9758 - ConferenceCam support blog https://www.youtube.com/watch?v=PsX6tIHo8no&feature=player_embedded - 1 min promotional video https://youtu.be/NMJjyupoysY - 3 min video by Ziva Nissan, Logitech Product Manager BCC950 data sheet 960-000866 2012 08.pdf - 2 pages 2012
